Donaldson Oval Exhaust 4" Inlet/Outlet - M120197

Donaldson Oval Exhaust 4" Inlet/Outlet - M120197

$542.77

Inlet Diameter 4.02 inch (102.11 mm)
Outlet Diameter 4.02 inch (102.11 mm)
Body Diameter Minimum 10.31 inch (262 mm)
Body Diameter Maximum 15.31 inch (389 mm)
Body Length 36.12 inch (917.5 mm)
Overall Length 42.00 inch (1066.8 mm)
Rated Flow LR 798 cfm (22.6 m³/min)
Rated Flow MR 1130 cfm (32 m³/min)
Rated Flow HR 1384 cfm (39.2 m³/min)
Back Pressure Low-Range 0.98 inch Hg (25 mm Hg)
Back Pressure Mid-Range 2.01 inch Hg (51 mm Hg)
Back Pressure High-Range 2.99 inch Hg (76 mm Hg)
Attenuation LR 22 dBA
Attenuation HR 28 dBA
Inlet Clock Position 3:00
Outlet Clock Position 9:00
Type Wrapped
Style Style 2

Filter Cross Reference:
A P PARTS-3675 ,3675Q ; AGCO-470263M91 ; AP EXHAUST PRODUCTS INC-3675 ; APE INDUSTRI AB-3675 ; ARGO-470263M91 ; CASE-CASE IH-3612162 ; CRANE CARRIER-21072 ,21083 ,2100083 ; FIAT-3612162 ; FMC-32H511 ,8A5810 ; FORD-D7HT5225BNA ; FREIGHTLINER-DNM120197 ; HANOMAG TRAKTOREN-4211754M91 ; HAVAM-HD9830 ; HEAVY DUTY MFG-31204 ; INGERSOLL RAND-56774953 ; LINK BELT-32H0511 ; MAREMONT-ZH003 ; MASSEY FERGUSON-470263M91 ; NAVISTAR-DCM120197 ; NELSON-86203M ; RIKER-15904W ; TAYLOR-2403077 ; TRUCKEX-3675 ; WALGAHN-MOTORENTECHN-810337 ,810337 ,810346 ,810346 ; WALKER MANUFACTURING-22843 ; WHITE-27076535 ,27076535 ,230010051
